OEM basic Escrow

Coin Counting Module

The OEM basic Escrow offers with its small dimensions a fully functional coin counting and deposit module with varying options. In addition, the system offers the option of an escrow, which ensures the possibility to return the coins after counting if desired. Due to its special self-cleaning mechanism, it is very resistant against foreign elements and dirt. The unit can be driven directly through its USB interface using one of the different available protocols for IT-integration. Innovative materials in industrial quality for coin-disk and coin-path ensure high counting speed – but on a low noise level.

Counting Technology
+ Counting speed up to 1.200 coins/minute
+ Pre-cleaning due to intelligent dirt-separators.
+ The Blockage Checker removes foreign objects automatically.
+ Multi Cash Sensor
+ ECB and Deutsche Bundesbank certified
+ Electromagnetic and capacitive coin detection
+ Matrix-sensor covering coin-characteristics
+ CCD-based diameter sensor

Escrow
+ Capacity 6,3 kg (Euro-coins)

Optional Items
+ Coin Tray (different variants)
+ Reject tray
+ Coin distributor

Supported Coin Bin Solutions
+ 2-bin system
+ 4-bin system
+ 6-bin system

Software
+ XFS-, MCRcf-driver
+ MC Suite Package
+ MC Monitoring Platform

Spezifications
Dimensions: 260 x 520 x 700 mm
Weight: 19,5 kg
